Ductile Iron Diaphragm Type Adjustable Pressure Reducing and Stabilizing Valve for Fire Fighting Water Direction Adjustment

Name: Ductile Iron Diaphragm Type Adjustable Pressure Reducing and Stabilizing Valve for Fire Fighting Water Direction Adjustment
Brand: Shanghai Jianggong Valve Manufacturing Co., Ltd.
SKU: YX8741X-JGPV
Price: 171.90 USD
Availability: InStock

Rincian produk

Tempat asal: Cina

Nama merek: JGPV

Nomor model: YX8741X-JGPV

Syarat Pembayaran & Pengiriman

Kuantitas min Order: 1 Set

Harga: USD75.9/Set - 269.9/Set

Kemasan rincian: Pengepakan keamanan kotak kayu lapis

Waktu pengiriman: 14 Hari

Syarat-syarat pembayaran: L/C,T/T,Western Union

Menyediakan kemampuan: 1000PCS Per Bulan

Dapatkan Harga Terbaik

Rincian produk

Deskripsi Produk

Menyoroti:
                                                                                                                                                                                                                                                                                                                                                                                ductile iron fire fighting valve, adjustable pressure reducing valve, diaphragm type water direction valve


Standar atau Non-standar:	Standar	Aplikasi:	Umum
Fungsi Produk:	Penyesuaian arah air pemadam kebakaran	Konstruksi:	Diafragma
Suhu kerja:	suhu normal	Aplikasi tekanan:	Tekanan Nomal
Kekuatan:	Hidrolik	Kerajinan manufaktur:	Pengecoran
Bahan Tubuh:	Besi Ulet	Garansi kualitas:	18 bulan

Standar atau Non-standar:	Standar
Aplikasi:	Umum
Fungsi Produk:	Penyesuaian arah air pemadam kebakaran
Konstruksi:	Diafragma
Suhu kerja:	suhu normal
Aplikasi tekanan:	Tekanan Nomal
Kekuatan:	Hidrolik
Kerajinan manufaktur:	Pengecoran
Bahan Tubuh:	Besi Ulet
Garansi kualitas:	18 bulan

Ductile Iron Diaphragm Type Adjustable Pressure Reducing and Stabilizing Valve for Fire Fighting Water Direction Adjustment

Diaphragm Type Adjustable Pressure Reducing Valve And Stabilizing Valve Ductile Iron

Product Overview

Ductile Iron Diaphragm Type Adjustable Pressure Reducing And Stabilizing Valve

Fire fighting valve products are control accessories on industrial and building pipelines. These valves are the most important controlled accessories, typically consisting of valve body, opening and closing mechanism, and valve cover. They feature simple structure and reliable sealing performance.

Most fire valves utilize clamp connections, simplifying the complex valve installation and pipeline connection process, making it fast and convenient. This represents a significant advancement in pipeline connection technology.

Technical Specifications

Parameter	Specification
Nominal Diameter DN (mm)	65~200
Nominal Pressure PN (MPa)	1.6/2.5
Test Pressure (MPa) - Strength (water)	2.4/3.8
Test Pressure (MPa) - Enclose (Water)	1.8/2.8
Working Temperature	0~80℃
Suitable Medium	Water

Product Features

High sensitivity, safety and reliability, easy debugging, and long service life
Stable pressure control with continuous pilot valve and main valve operation
Downstream pressure changes continuously and steadily with minimal influence from inlet pressure
Filter should be installed in front of the valve for easy discharge of pollutants

Application Benefits

The YX8741X diaphragm adjustable pressure reducing and stabilizing valve is used in parallel water supply systems for firefighting and domestic use. During fire emergencies, it automatically cuts off domestic water to ensure sufficient fire water supply. When fire water pressure decreases, the valve automatically opens to restore domestic water supply, eliminating the need for separate fire-fighting water supply networks and significantly reducing construction costs and water consumption.
