Digital Locking Hydraulic Flow Control Valve with Threaded Brass and Low-Temperature Static Balance Cut-off Valve

Rincian produk

Tempat asal: Cina

Nama merek: JGPV

Syarat Pembayaran & Pengiriman

Kuantitas min Order: 1set

Kemasan rincian: Pengepakan keamanan kotak kayu lapis

Waktu pengiriman: 14 hari

Syarat-syarat pembayaran: L/C,T/T,Western Union

Menyediakan kemampuan: 500 set per bulan

Dapatkan Harga Terbaik

Rincian produk

Deskripsi Produk

Menyoroti:
                                                                                                                                                                                                                                                                                                                                                                                                                Digital Locking Static Balance Valve, Threaded Brass Cut-off Valve, Low-Temperature Flow Control Valve


Aplikasi::	Umum	Sertifikat::	ISO9001, ISO14001
Tipe Menengah::	Air, uap dan minyak dll.	Koneksi::	Berulir / bergelang / dilas
Standar atau non-standar::	Standar	Cara mengalir::	Dua arah
Aktuasi::	Manual, listrik, pneumatik, otomatis	Kinerja Sealing::	Penyegelan
Suhu Kerja::	Suhu normal dan suhu tinggi	Aplikasi Tekanan::	tekanan normal
Garansi Kualitas::	18 bulan

Aplikasi::	Umum
Sertifikat::	ISO9001, ISO14001
Tipe Menengah::	Air, uap dan minyak dll.
Koneksi::	Berulir / bergelang / dilas
Standar atau non-standar::	Standar
Cara mengalir::	Dua arah
Aktuasi::	Manual, listrik, pneumatik, otomatis
Kinerja Sealing::	Penyegelan
Suhu Kerja::	Suhu normal dan suhu tinggi
Aplikasi Tekanan::	tekanan normal
Garansi Kualitas::	18 bulan

Digital Locking Hydraulic Flow Control Valve with Threaded Brass and Low-Temperature Static Balance Cut-off Valve

Digital Locking Hydraulic Flow Control Cut-Off Valve

Low-temperature threaded thickened brass static valve for industrial and commercial heating systems

Product Overview

Our digital lock balance valve is an advanced energy-saving valve with specialized functionality. Featuring digital display and locking mechanisms, this valve enables precise adjustment to any position and includes pressure measurement capabilities for flow monitoring. Primarily designed for industrial and civil building heating pipeline systems, it offers superior flow characteristics, accurate pressure drop and flow rate adjustment, and efficient flow distribution.

Technical Specifications

Parameter	Specification
Model	SP45F-16Q
Test Pressure	2.4 MPa (24 kgf/cm²)
Working Pressure	≤1.6 MPa (16 kgf/cm²)
Operating Temperature	-10℃ to 100℃
Compatible Medium	Water
Characteristic Curve	Equal Percentage
Installation Scope	Main trunk lines, branch trunks, indoor water supply mains, branch risers, and multiple boiler pipeline systems

Installation Requirements

Install sufficient length of branch pipe sections before and after the static balance valve to ensure rated flow rate output
Verify installation position according to drawings, typically on HVAC system return pipelines
Confirm water flow direction and install strictly following the flow arrow direction on valve body
Thoroughly clean pipeline debris before installation - prohibit welding slag, branches, stones, or other debris
Avoid excessive deformation and welding angles during pipeline flange welding that could affect sealing surface flatness
After installation, fully open valve for repeated pipeline flushing until clean - do not repeatedly close valve during flushing

Product Images
